GRACE M(7018)
6013+
APPLICATIONS

Low hydrogen welding electrodes with superior impact resistance at room and sub-zero temperatures. Ideal for high-pressure piping, blast furnaces, heavy fabrication, penstocks, bridges, pressure vessels, cranes, steel gears, and loco frames.

CHARACTERISTICS

An all positional, medium heavy coated, iron powder type, low hydrogen electrode depositing radiographic quality welds which are highly resistant to hydrogen induced cracking. Welds beads are smooth and spatter level is low. Works well on AC and DC.

CLASSIFICATION

ASME SFA 5.1, E7018
IS 814-04, EB - 5426 H3JX

WELD METAL COMPOSITION

C: 0.05 - 0.09

Mn: 0.80 - 1.40

Si: 0.20 - 0.70

P: 0.03 Max

S: 0.03 Max

MECHANICAL PROPERTIES

UTS: 520 - 610 N/mm²

YS: 400 - 560 N/mm²

Elongation: 22% Min (L=4d)

Reduction of Area: 55 - 75%

CVN Impact Value (J)

+27°C: 140 Min

0°C: 100 Min

-20°C: 80 Min

-30°C: 50 Min

CURRENT RANGE (AC/DC ±)

2.5mm: 60 - 90A

3.15mm: 90 - 130A

4.0mm: 130 -170A

5.0mm: 170 -230A

PACKING SIZE

2.50 x 350 | 3.15 x 450 | 4.00 x 450 | 5.00 x 450 | 6.30 x 450

APPROVALS

BIS

Each Box Contains 4 Cartons
