GRACE M(308)
6013+
APPLICATIONS

Suitable for welding ferritic steels of 13 to 17% Chromium. For welding of AISI types: 301, 302, 304, and 308.Used for building up surfaces of pump impellers, shafts, and other components in chemical plants, machinery, food, and dairy plants

CHARACTERISTICS

An all positional radiographic quality, 19/10 stainless Steel electrode with controlled ferrite content for maximum resistance to corrosion and cracking. Weld metal has excellent creep strength & resistance to inter- crystalline corrosion. Arc is stable and weld deposits are smooth, uniform and of excellent appearance. Slag detachability is good.

CLASSIFICATION

ASME SFA 5.4, E308 - 16

WELD METAL COMPOSITION

C: 0.04 - Max

Mn: 0.50 - 2.50

Si: 0.90 - Max

Cr: 18 - 21

Ni: 9 - 11

P: 0.03 Max

S: 0.03 Max

MECHANICAL PROPERTIES

UTS: 550 - min N/mm²

Elongation: 30% Min (L=4d)

CURRENT RANGE (AC/DC ±)

2.5mm: 40 - 60A

3.15mm: 70 - 100A

4.0mm: 100 - 140A

5.0mm: 130 - 170A

PACKING SIZE

2.50 x 350 | 3.15 x 350 | 4.00 x 350 | 5.00 x 350

Each Box Contains 4 Cartons
